| Brand Name: | YT |
| Model Number: | OR p3.91 |
| MOQ: | 1pcs |
| Delivery Time: | 15 to 20 days |
| Payment Terms: | L/C, D/A, T/T |
| The technical details for this stage and events use LED display is as below, | ||||||||
| Parameter | ||||||||
| Environmental | INDOOR | OUTDOOR | ||||||
| Pixel Pitch | 1.9 | 2.6 | 2.9 | 3.9 | 4.8 | 2.6OD | 2.9OD | 3.9OD |
| LED Configuration | SMD1515 | SMD1515 | SMD2020 | SMD2020 | SMD2020 | SMD1415 | SMD1921 | SMD1921 |
| Pixel Density | 262144dot/m2 | 147456dot/m2 | 112896dot/m2 | 65536dot/m2 | 43264dot/m2 | 147456dot/m2 | 112896dot/m2 | 65536dot/m2 |
| Module Size | 250X250mm | 250X250mm | 250X250mm | 250X250mm | 250X250mm | 250X250mm | 250X250mm | 250X250mm |
| Module Resolution | 128*128dot | 96x96dot | 84x84dot | 64x64dot | 52x52dot | 96x96dot | 84x84dot | 64x64dot |
| Cabinet Size | 500x500mm | 500x500mm | 500x500mm | 500x500mm | 500x500mm | 500x500mm | 500x500mm | 500x500mm |
| 500x1000mm | 500x1000mm | 500x1000mm | 500x1000mm | 500x1000mm | 500x1000mm | 500x1000mm | 500x1000mm | |
| Cabinet Resolution | 256X256dot | 192X192dot | 168X168dot | 128X128dot | 104X104dot | 192X192dot | 168X168dot | 128X128dot |
| Cabinet Weight | 7KG/ PCS | 7KG/ PCS | 7KG / PCS | 7KG / PCS | 7KG/ PCS | 7.5KG/ PCS | 7.5KG / PCS | 7.5KG / PCS |
| IP Rating ( front/back) | IP40 | IP40 | IP40 | IP40 | IP40 | IP65/43 | IP65/43 | IP65/43 |
| Brightness | 600CD/m2 | 850CD/m2 | 850CD/m2 | 850CD/m2 | 850CD/m2 | 4000CD/m2 | 4000CD/m2 | 4000CD/m2 |
| Viewing Angle (H/V) | 120° | 120° | 120° | 120° | 120° | 120° | 120° | 120° |
| Gray Scale | 14bit | 14bit | 14bit | 14bit | 14bit | 14bit | 14bit | 14bit |
| Max.Power Consumption | 800 W/m² | 800 W/m² | 800 W/m² | 800 W/m² | 800 W/m² | 800 W/m² | 800 W/m² | 800 W/m² |
| Ave.Power Consumption | 260 W/m² | 260 W/m² | 260 W/m² | 260 W/m² | 260 W/m² | 260 W/m² | 260 W/m² | 260 W/m² |
| Refresh Frequency | ≥3840HZ | ≥3840HZ | ≥3840HZ | ≥3840HZ | ≥3840HZ | ≥3840HZ | ≥3840HZ | ≥3840HZ |
| Brightness Adjustment | 0 - 100 levels adjustable | |||||||
| Operation Power | AC100/240 50/60HZ | |||||||
| Operating Temperature | - 20ºC~+50ºC | |||||||
| Operating Humidity | 10~90% RH | |||||||
| Operating Life | 100,000hours | |||||||
